Tripod Turnstile

Tripod Turnstile Specification

Interface
RS485, Dry Contact Relay, Optional TCP/IP

Size
Approx 1200 mm (L) x 280 mm (W) x 980 mm (H)

Standard
CE, ISO 9001:2015 Compliant

Operating Mode
Single/Dual Direction, Controlled or Free-pass Modes

Mounting Type
Floor Mounted

License Free
Yes

Connectivity Type
Wired, Can Be Integrated With RFID/Biometric Devices

Technology
Electro-mechanical Tripod Mechanism

Special Features
Bi-directional passage, Automatic Arm Drop in Case of Emergency, Anti-tailgating, Integrated Access Control Compatibility

Remote Control
Available (Optional for Integration)

Application
Office Buildings, Metro Stations, Stadiums, Airports, Corporate Lobbies, Restricted Areas

Power Supply
220V AC 10%, 50Hz; 24V DC Motor Operation

Output Formats
Dry Contact Relay Output, RS485 Interface

Ingress Protection
IP54

Passage Width
550 mm

Flow Rate
25-35 persons/minute

Control System
Microprocessor Controlled

Net Weight
Approx. 50 kg

Material
304 Stainless Steel Housing

Indicative Lights
LED Direction Indicators

Surface Finish
Brushed Stainless Steel

Emergency Mode
Automatic Arm Drop During Power Failure or Fire Alarm Signal

Maintenance
Low Maintenance, Brushless Motor

Unlock Time
0.2 seconds

Integration
Compatible with RFID, Biometric, Barcode, QR Code Readers

Noise Level
60dB

Arm Length
500 mm

Operating Temperature
-20C to +60C

About Tripod Turnstile

Owing to our fair business policies, we have been successfully engaged in manufacturing, exporting and supplying a broad range of Tripod Turnstile. The offered tripod is widely used to support the adjustable feet of instrument during survey. This tripod is manufactured under the proper supervision of our diligent professionals using quality checked steel with the aid of progressive techniques. Additionally, the provided Tripod Turnstile can be purchased from us in bulk at economical prices.

Key Details:

Advanced microprocessor controlled electronics
Fine mechanics processed on CNC machines
Contact-less position sensing technology
Hydraulic damper with adjustable damping ratio
Hardened steel cam manufactured on CNC machines

Advanced Access Control Integration

This tripod turnstile is designed for seamless integration with a variety of access control systems, including RFID, biometric, barcode, and QR code readers. Its microprocessor-controlled system and RS485 interface (with optional TCP/IP connectivity) ensure reliable, real-time communication, making it compatible with modern security networks. This flexibility allows for easier upgrades and secure, customized solutions for any restricted area.

Built for Durability and Safety

Manufactured from 304 stainless steel with a brushed finish, the turnstile withstands harsh indoor and covered outdoor conditions, operating efficiently between -20C to +60C. Its emergency mode includes an automatic arm drop when triggered by power failure or fire alarm, providing safe, obstruction-free evacuation routes and enhancing overall safety compliance.

FAQs of Tripod Turnstile:

Q: How does the tripod turnstile respond during emergencies or power failures?

A: During a power failure or upon receiving a fire alarm signal, the turnstiles arm automatically drops to allow for unobstructed emergency evacuation, ensuring user safety without manual intervention.

Q: What are the primary benefits of installing this tripod turnstile in my facility?

A: The turnstile offers secure, efficient management of pedestrian flow, integrates easily with various access control systems, supports both single and bi-directional passage, and features anti-tailgating to prevent unauthorized access. Its robust build and low maintenance requirements enhance reliability and reduce operational costs.

Q: Where can this turnstile be installed and what types of applications is it suited for?

A: This tripod turnstile is ideal for installation in office buildings, metro stations, stadiums, airports, corporate lobbies, and other restricted areas requiring controlled pedestrian access and efficient throughput.

Q: How is the device integrated with access control systems such as RFID or biometric readers?

A: Integration is achieved via standard interfaces like RS485, dry contact relay, and optional TCP/IP connectivity. The turnstile is compatible with RFID, biometric, barcode, and QR code readers for customized security solutions.

Q: What is the process for controlling the passage mode or access direction?

A: Operators can configure the turnstile through its microprocessor control system for either single or dual direction, as well as switch between controlled access or free-pass modes based on site requirements.

Q: What is the maintenance requirement and expected operational noise level of the turnstile?

A: Thanks to its brushless motor and durable electro-mechanical components, the turnstile requires minimal maintenance and operates at a noise level of 60dB, offering a quiet, dependable solution.
